Item
|
FSL-5D
|
|
Illumination Tilting
|
5°,10°,15°,20°
|
Software:
|
Embedded software, OD/OS auto recognition, image or video acquisition, image processing & marking, diagnostic reports output.
|
|
Illumination Type
|
Haag-Streit Type
|
|
Eyepiece Magnification
|
12.5X
|
|
Slit Width
|
0mm～14mm Continuously Adjustable
|
Fixation:
|
Red LED
|
|
Slit Length
|
1mm～14mm Continuously Adjustable
|
Light Control:
|
Stepless dimming on the base
|
|
Slit Angle
|
0～180°Continuously Adjustable
|
Voltage:
|
100V-240V 50/60 Hz
|
|
Filter
|
Heat Aborption, Grey, Redfree (Green), Cobalt Blue
|
Eyepiece Luminous ：
Camera Luminous
|
60% ：40%
|
|
Light Source
|
Warm LED
|
Slit Aperture Size
|
φ0.2，φ1，φ3，φ5，φ10，φ14（mm）
|
|
Magnification
|
6.3X,10X,16X,25X,40X
|
Microscope Type
|
Galilean Dystem
|
|
Diopter
|
±7D
|
Magnification
Changer
|
Revolving Drum
|
|
Pupil Range
|
52-82mm
|
Visual Field Diameter
|
6X:33mm；10X:22mm；16X:14mm；25X:8.5mm；40X:5.5mm
|
