Features:
7-inch HD LCD touch screen with resolution of 1024*600. Left and right glasses piece graphics 1:1 display
A 3-second rapid optical or mechanical scanning
Scan data can be saved. You can store 500 template data
Graphic Menu is convenient for identification and customer operation
The parameter adjustment pre-setting can avoid some calibration maintenance
The preview interface can quickly input the pupil distance and pupil height
It can meet the processing requirements of different materials lenes (includingCR-39, PC, high fold, hard sheet, glass etc.)
Built-in pointed edge, flat edge polished grinding wheel, built-in slot, inverted edge function
Rich sharp edge and slotted processing mode, to meet the needs of different frames (automatic,33%,55%, front bend, backbend, manual sharp edge etc.)
Specifications:
Dimension: L*W*H (720mm x653mmx453mm)
Weight: 75Kg
Voltage: AC100~240V 50/60Hz
Power: 1500W
Water Pump Voltage: AC100~240V 50/60Hz
Water Pump Electric Power: <350W
Working Noise: <72dB
Operating Ambient Temperature: 5°℃~40°℃
Edge Diameter: ≤80mm
Flat Edge Processing (No Safety Edge): >19.00mm
Tip Machining (No Safety Edge): >19.00mm
Mechanical Scanning Range:
Width Scan Size: Min 20mm, Max 58mm
Length Scan Size: Min 30mm, Max 68mm
Frame Thickness: Min 2.0mm, Max 16mm
